Telemetry Comparison
Please check this brief comparison table of our telemetry lineup, if you have any questions please contact us
|  |  |  |  |  |
Telemetry | 3DR Radio 2 | Long Range 1W | 3DR1060 | 3DR1060 Air | Dual Band WiFi Telemetry |
Status | in production | in production | in production | in production | in production |
PN | R7002 | M10084 | M10131 | M10135 | M10114 |
HW revision | B | H | C | B | C |
Firmware | proprietary, customizable on-demand | Ardupilot SiK | Ardupilot SiK | Ardupilot SiK | proprietary, customizable add-ons |
Radio Module | 802.11ah | Si1030 | Si1060 | Si1060 | u-Blox ODIN-W2 |
Frequency (* alternate freq is a different board) | Sub-1 GHz | 915/433 MHz* | 915/433 MHz* | 915/433 MHz* | 2.⅘ GHz |
Max. output power | 23 ± 2 dBm | 28 dBm | 20 dBm | 20 dBm | 18 dBm |
Mechanical related | | | | | |
Dimensions w/o antenna(s) (length x width) | 44.5mm x 35mm | 54.7 mm x 24.7 mm | 55.7 mm x 25.7 mm | 30 mm x 19 mm | 34.4 mm X 24.8 mm |
Dimensions w/o antenna(s) (height) | 13.8 mm | 11.7 mm | 13mm | 9.5 mm [3mm w/o JST] | 4 mm |
Weight | 8.7 g | 17.3 g | 14.4 g | 15.5 g | 3.6 g |
Weight w/ antenna(s) | TBD | Default: 63.6g / Opt. Two: 45.2g | 22.9 g | | none |
Case | aluminum [25 g total] | aluminum | plastic | none | none |
Peripherals | | | | | |
USB | yes | no | yes | no | no |
UART | yes | yes | yes | yes | yes |
CAN | no | no | no | no | no |
I2C | no | no | no | no | yes |
Ethernet | yes | no | no | no | no |
Power | | | | | |
Input voltage | 5V | 5V | 5V | 5V | 5V |
Max. current | TBD | 1.1 A | | | |
